MB ASUS A520 AMD S-AM4 5A GEN/4X DDR4 2800/DP/HDMI/D-SUB/M.2/4X USB3.2/MICRO ATX/GAMA BASICA/CSM

SOCKET AMD AM4: LISTO PARA PROCESADORES DE ESCRITORIO RYZEN 5000 SERIES / 5000 G-SERIES / 4000 G-SERIES / 3000 SERIES.

REFRIGERACIóN COMPLETA: DISIPADOR DE CALOR VRM, DISIPADOR DE CALOR PCH Y FAN XPERT 2+.

CONECTIVIDAD ULTRARRáPIDA: COMPATIBILIDAD CON M.2, ETHERNET DE 1 GB, USB 3.2 GEN 1 TIPO A.

AURA SYNC RGB: PUERTOS RGB INTEGRADOS Y PUERTOS GEN 2 DIRECCIONABLES PARA TIRAS DE LED RGB, QUE SE SINCRONIZAN FáCILMENTE CON HARDWARE COMPATIBLE CON AURA SYNC.

ASUS CONTROL CENTER EXPRESS (ACCE) PARA UNA GESTIóN DE TERMINALES DE TI MáS SENCILLA.

CPU

AMD RYZEN 5000 SERIES/ 5000 G-SERIES/ 4000 G-SERIES/ 3000 SERIES DESKTOP PROCESSORS

* REFER TO WWW.ASUS.COM FOR CPU SUPPORT LIST

CHIPSET

A520

MEMORIA

CANALES DE MEMORIA:4 X DIMM, MAX. 128GB, DDR4

4800(OC)/4600(OC)/4466(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/3000/2800/2666/2400/2133 MHZ, UN-BUFFERED MEMORY*

DUAL CHANNEL MEMORY ARCHITECTURE

*ECC MEMORY (ECC MODE) SUPPORT VARIES BY CPU.

* REFER TO WWW.ASUS.COM FOR THE MEMORY QVL (QUALIFIED VENDORS LISTS), AND MEMORY FREQUENCY SUPPORT DEPENDS ON THE CPU TYPES.

GRáFICOS

1 X DISPLAYPORT 1.2

1 X D-SUB

1 X HDMI® PORT***

* GRAPHICS SPECIFICATIONS MAY VARY BETWEEN CPU TYPES

RANURAS DE EXPANSIóN

AMD RYZEN 5000 SERIES/ 5000 G-SERIES/ 4000 G-SERIES/ 3000 SERIES DESKTOP PROCESSORS

1 X PCIE 3.0 X16 SLOT (SUPPORTS X16 MODE)

AMD A520 CHIPSET

2 X PCIE 3.0 X1 SLOTS

ALMACENAMIENTO

SUPPORTS 1 X M.2 SLOT AND 4 X SATA 6GB/S PORTS

AMD RYZEN 5000 SERIES/ 5000 G-SERIES/ 4000 G-SERIES/ 3000 SERIES DESKTOP PROCESSORS

M.2 SLOT (KEY M), TYPE 2242/2260/2280 (SUPPORTS PCIE 3.0 X4 AND SATA MODES)

AMD A520 CHIPSET

4 X SATA 6GB/S PORTS

SUPPORT RAID 0, 1, 10

USB

USB TRASERO:TOTAL 6 PORTS

4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)

2 X USB 2.0 PORTS (2 X TYPE-A)

USB FRONTAL:FRONT USB PORT ( TOTAL 6 )

1 X USB 3.2 GEN 1 HEADER SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 PORTS

2 X USB 2.0 HEADERS SUPPORT ADDITIONAL 4 USB 2.0 PORTS

AUDIO

ALC887/897

REALTEK ALC887/897 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC*

- SUPPORTS : JACK DETECTION, MULTI-STREAMING, FRONT PANEL JACK-RETASKING

- SUPPORTS UP TO 24-BIT/192 KHZ PLAYBACK

AUDIO FEATURES

- AUDIO SHIELDING

- PREMIUM JAPANESE AUDIO CAPACITORS

- DEDICATED AUDIO PCB LAYERS

*A CHASSIS WITH AN HD AUDIO MODULE IN THE FRONT PANEL IS REQUIRED TO SUPPORT 7.1 SURROUND SOUND AUDIO OUTPUT.

PUERTOS E/S TRASEROS

4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A)

2 X USB 2.0 PORTS (2 X TYPE-A)

1 X DISPLAYPORT

1 X HDMITM PORT

1 X D-SUB

1 X REALTEK 1GB ETHERNET PORT

3 X AUDIO JACKS

1 X PS/2 KEYBOARD/MOUSE COMBO PORT

PUERTOS INTERNOS

FAN AND COOLING RELATED

1 X 4-PIN CPU FAN HEADER

2 X 4-PIN CHASSIS FAN HEADERS

POWER RELATED

1 X 24-PIN MAIN POWER CONNECTOR

1 X 8-PIN +12V POWER CONNECTOR

STORAGE RELATED

1 X M.2 SLOT (KEY M)

4 X SATA 6GB/S PORTS

USB

1 X USB 3.2 GEN 1 HEADER SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 PORTS

2 X USB 2.0 HEADERS SUPPORT ADDITIONAL 4 USB 2.0 PORTS

MISCELLANEOUS

2 X AURA ADDRESSABLE GEN 2 HEADER

2 X AURA RGB HEADERS

1 X CLEAR CMOS HEADER

1 X COM PORT HEADER

1 X FRONT PANEL AUDIO HEADER (AAFP)

1 X S/PDIF OUT HEADER

1 X SPEAKER HEADER

1 X SPI TPM HEADER (14-1PIN)

1 X 10-1 PIN SYSTEM PANEL HEADER

FUNCIONES ESPECIALES DE ASUS

ASUS 5X PROTECTION III

- DIGI+ VRM

- LANGUARD

- OVERVOLTAGE PROTECTION

- SAFESLOT CORE

- STAINLESS-STEEL BACK I/O

ASUS Q-DESIGN

- ASUS Q-DIMM

- ASUS Q-SLOT

ASUS THERMAL SOLUTION

- VRM HEATSINK DESIGN

AURA SYNC

- AURA RGB HEADERS

- ADDRESSABLE GEN 2 RGB HEADERS

SOFTWARE

ASUS EXCLUSIVE SOFTWARE

ARMOURY CRATE

- AURA CREATOR

- AURA SYNC

AI SUITE 3

- PERFORMANCE AND POWER SAVING UTILITY

TURBOV EVO

EPU

DIGI+ VRM

FAN XPERT 2+

- EZ UPDATE

ASUS CPU-Z

AI CHARGER

DAEMON TOOLS

NORTON ANTI-VIRUS SOFTWARE (FREE TRIAL VERSION)

WINRAR

UEFI BIOS

ASUS EZ DIY

- ASUS CRASHFREE BIOS 3

- ASUS EZ FLASH 3

- ASUS UEFI BIOS EZ MODE

BIOS

128 MB FLASH ROM, UEFI AMI BIOS

MANEJABILIDAD

WOL BY PME, PXE

ACCESORIOS

CABLES

2 X SATA 6GB/S CABLES

MISCELLANEOUS

1 X I/O SHIELD

1 X M.2 SSD SCREW PACKAGE

INSTALLATION MEDIA

1 X SUPPORT DVD

DOCUMENTATION

1 X USER MANUAL

SISTEMA OPERATIVO

WINDOWS® 10 64-BIT

WINDOWS® 7 64-BIT *1

FACTOR DE FORMA

MATX

9.6 INCH X 9.6 INCH ( 24.4 CM X 24.4 CM )
